Rail
Supporting propulsion system modeling, thermal management, and energy efficiency analysis for rail applications.
INDUSTRY OVERVIEW
Complete Rail Simulation, From Compressors to Propulsion
Gamma Technologies is the developer of GT-SUITE, the industry-leading Model-Based Systems Engineering (MBSE) CAE system simulation software. GT-SUITE provides a comprehensive set of validated 0D/1D/3D multi-physics component libraries, which simulate the physics of fluid flow, thermal, mechanical, multi-body, structural, electrical, magnetic, chemistry, and controls.
Utilizing combinations of these libraries, accurate models can be built of practically any rail system, such as train diesel-electric propulsion, train air brakes and many more. This makes GT-SUITE the ideal rail system simulation software.
SIMULATION FEATURES
Powerful Simulation Features Include
Highly Scalable
Solve large systems containing thousands of components, with fast execution speed and robustness
Full Range of System Analyses
Performs the full range of system analysis from the initial set of requirements, to detailed component design, to system integration, to control, HiL and calibration, and even to on-board CPU model based control
Robust Navier-Stokes Solver
GT-SUITE offers simulations based on a Navier-Stokes flow solution, which simultaneously solves conservation of mass, momentum, energy and species, and is uniquely stable
Full 3D Analyses Capabilities
A system simulation tool at its core, strengthened by capability to perform full 3D analysis (CAD, FEA, CFD)
3D-2D-1D Multi Body Components
GT-SUITE’s 3D-2D-1D Multi Body components are integrated with the surrounding multi-physics systems which provide their boundary conditions
Automatically Create Flow, Thermal & Mechanical 1D and 3D Models
Automatically creates flow, thermal and mechanical 1D and 3D models from 3D CAD solids
Built-in DOE and Optimization
GT-SUITE offers a built-in DOE and optimization package, and offers links with leading third party optimization tools
Exceptional Value
GT-SUITE offers an exceptional value: runs models of complex integrated systems using just one license
